Stainless Steel Belleville Washer Standard: DIN9250 Type: Butterfly Washer
164.34 USD(tax included)
／295.81 USD (Excluding tax)
Sales unit: 1 piece
Application number: / Manufacturer: / Model number: m47973717140 / JAN code: / AS ONE / NAVIS Product number:
| Application number | |
|---|---|
| Manufacturer | |
| Model number | m47973717140 |
| JAN code | |
| Sales unit | 1 piece |
| Price | 164.34 USD (tax included) / 295.81 USD (Excluding tax) |
*Additional shipping fees will be charged for this product in Okinawa Prefecture, remote islands, some other areas, and mountain areas. Please note that we may not be able to deliver depending on the region. If we are unable to deliver your order after placing your order, Askul will contact you.
Please note the following points as this item is directly shipped.
- Additional shipping fees will be charged for this product in Okinawa Prefecture, remote islands, some other areas, and mountain areas. Please note that we may not be able to deliver depending on the region. If we are unable to deliver your order after placing your order, Askul will contact you.
- This product may not come with a delivery note issued by Askul. Customers who wish to receive a delivery note issued by Askul can print it out as a PDF file from the usage history on this site after receiving the product.
- It is not delivered in Askul cardboard or a bag.
- We cannot accept changes, cancellations, returns, or exchanges after the order has been placed due to the customer's convenience.
- If we discover after placing an order that the product cannot be delivered, we may cancel your order.
- If it becomes clear after placing your order that the item is temporarily out of stock, it will be delivered as soon as it becomes available.
This image is a representative image. Please check the specifications for details.
Stock: Slightly
Direct delivery product
Shipping charges for products from this shipping source will be borne by us.
58 USD (tax included)
/ 63.8 USD (Excluding tax)
Product details
Print product information
| Product features | Category Washers & Flat Washers Condition New/unused Shipping Included in price (by seller) From Unspecified |
||
|---|---|---|---|
| Manufacturer name | - | Brand name | - |
| remarks | [About returns] We cannot accept returns due to customer's convenience. | ||
| Product details |
Compared to standard spring washers, these have stronger serrations (ridges) and a unique curve on their surface, demonstrating their true value in harsh vibration environments. 1. Basic Usage Usage is very simple, but orientation is important. ? Where to place: Place between the bearing surface of the bolt (or nut) and the object being tightened. ? Orientation: Face the ridged side (the raised side) towards the bolt head, and the valley side towards the object. ? Tightening: As the bolt is tightened, the butterfly washer is compressed and tries to flatten. The **force to return (repulsive force)** at this time strongly presses the bolt's threads, creating frictional resistance. 2. Main Applications Often used in places where loosening is absolutely unacceptable and vibration is severe. ? Automotive and motorcycle suspension: Areas subjected to subtle vibrations from the engine and impacts during driving. ? Industrial and machine tools: Devices incorporating motors or rotating parts that are constantly exposed to vibration. ? Electrical contacts and terminal blocks: Places where constant pressure needs to be applied to prevent contact failure due to aging. ? Elevators and railway-related equipment: Critical safety components where safety is paramount and maintenance frequency needs to be minimized. 3. Benefits of Butterfly Washers Why use these instead of regular flat washers or spring washers? ? High holding power: The unevenness of the surface slightly bites into the mating material, physically preventing rotation. ? Space saving: Because they are very thin, a high locking effect can be achieved even in areas where the bolt's underhead length is short. ? Bolt protection: The load is evenly distributed around the circumference, reducing uneven stress on individual bolts. Precautions for Use Butterfly washers enhance their effectiveness by biting into the mating material, so they may scratch the surface of the object (paint, etc.). Also, if the mating material is very hard (e.g., hardened steel), they may not bite in sufficiently to provide adequate effectiveness. Click here for the manufacturer's site
